The full bore brass ball valve 576 BSP with wide flat bearing for shut-off of water, heating, sprinkling, irrigation, air conditioning and compressed air systems.
| Specification | Value |
|---|---|
| DN inches NPS | 1/8'' |
| DN metric | 5/10 |
| Brand | AIRAGA |
| Thread standard | ISO 228-1 |
| Stem sealing material | PTFE Gland packing + EPDM O-ring |
| Type of coating | Nickel-plated |
| Opening device | Handle |
| Application | Industry |
| Shaft/stem matérial | Brass CW614N |
| DN | DN5 |
| Face to Face (mm) | 37.7 |
| Fluid | Cold water |
| Body material | Brass CW617N |
| Number of ways | 2 |
| Bore | Full |
| Packing gland | Yes |
| PS (bar) | 40 |
| Connections | BSP FF |
| Seats | PTFE |
| Ball material | Chrome-plated brass CW617N |
| TS max (°C) | 120 |
| TS min (°C) | -10 |
| Warranty period | 2 years |
| Handle material | Carbon steel |
| Handle type | Red lever |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP FF Brass CW617N Full 1/8'' | 576001 | S1009951 |
€5.41
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1/4'' | 576002 | S1009952 |
€5.41
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 3/8'' | 576003 | S1009953 |
€5.41
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1/2'' | 576004 | S1009954 |
€8.24
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 3/4'' | 576005 | S1009955 |
€11.67
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1'' | 576006 | S1009956 |
€18.09
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1''1/4 | 576007 | S1009957 |
€28.16
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 1''1/2 | 576008 | S1009958 |
€42.23
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 2'' | 576009 | S1009959 |
€63.33
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 2''1/2 | 576010 | S1009960 |
€112.87
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 3'' | 576011 | S1009961 |
€171.56
(excl. btw)
|
add to cart |
| BSP FF Brass CW617N Full 4'' | 576012 | S1009962 |
€305.43
(excl. btw)
|
add to cart |
